Charbroil 463870109 Grill Parts

Charbroil logo



Charbroil 463870109

Char-Broil LP gas outdoor BBQ grill with side burner



Highest quality replacement parts for your Charbroil 463870109 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463870109 owners manual and diagrams
Click the small images on the right to view Charbroil 463870109 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 463870109-463512989030-PartsExpS1.jpg

Replacement BBQ grill parts for Charbroil model: 463870109
This page shows all of the parts we know fit model Charbroil 463870109. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 463870109 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463870109 Cooking Grids

CG-DUMMY
Cooking grid not known for Charbroil model 463870109. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Charbroil cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0






463870109 Heat Plates

Porcelain steel heat tent for Charbroil model 463870109. Sold individually.

Part Number: 91091 (Replaces Charbroil 80009181)
Dimension Front-to-Back: 26 15/16”
Dimension Side-to-Side: 6 1/8”
Material: porcelain steel
Weight: 2.5

$37.84

Qty








463870109 Igniter Components

Electrode, collector box with connector wire that has a female spade end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03080 (Replaces Charbroil 80011620)
Material: ceramic
Weight: 0.05

$9.25

Qty








463870109 Knobs and Handles

Universal black control knob. Counter-clockwise bezel.
  • Off position D-Value: Selectable
  • Knob diameter: 2 1/16”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

$6.55

Qty


Black control knob for Fire Magic Custom, Regal, and Gourmet grills.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

$10.84

Qty








463870109 Accessories

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

$25.40

Qty


Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

$13.30
SALE  $14.99
Qty


Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

$4.93

Qty






BBQ Part Categories


























Charbroil gas grill 463870109 - Thursday, Sep 5 2024

Return to Charbroil grill parts main page



More Charbroil grill models we have parts for
GG8042 | GG8043 | GG8044 | GG8045 | GG8046 | GG8046-1 | GG8048 | GG8049 | GG8055 | GG8056 | GG8056-1 | GG8057 | GG8060 | GG8060-1 | GG8061 | GG808 | GG8132 | GG8133 | GG8134 | GG8135 | GG8136 | GG8137 | GG8138 | GG8140 | GG8144 | GG8145 | GG8147 | GG8170 | GG8171 | GG8172 | GG8173 | GG8174 | GG8230 | GG8233 | GG8234 | GG8235 | GG8236 | GG8237 | GG8238 | GG8239 | GG8240 | GG8270 | GG8271 | GG8272 | GG8273 | GG8276 | GG8277 | GG8278 | GG8279 | GG831 | Complete list of Charbroil grill models...



*Orders for Charbroil grill model 463870109 $49 and over ship free to the lower 48 states.
See shipping policy below for more info.
