Coleman 5100 9991-132 Grill Parts

Coleman 5110 Natural Gas Series

Highest quality replacement parts for your Coleman 5100 9991-132 - Free USA shipping $49 or more* - No Sales Tax*

Coleman 9991-132 owners manual and diagrams

Click the small images on the right to view Coleman 9991-132 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Coleman 9991-132-30008885431-PartsExpS1.jpg

Coleman 9991-132-30008885431-PartsLstS1.jpg

Replacement gas grill parts for Coleman 5100 9991-132

All of the parts we have for Coleman 9991-132 are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Coleman grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Coleman 9991-132 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Coleman model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

9991-132 Burners

Click for photos

Cast iron burner for Coleman model 9991-132.

Part Number: CIT
Dimensions: 15 3/4” x 2 7/8”
Material: cast iron
Weight: 4.2

Click for photos

Cast stainless steel burner for Coleman model 9991-132. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design.

NOTE: This burner is equiped with an air intake adjustable control shutter (not shown in photos) and with an air intake control screw for regulating the air/gas mixture into the burner. Natural gas applications require more air (more open screw) than lquid propane (LP). If necessary, adjust screw to get a yellow-tipped blue flame.

Part Number: 23301-CSS
Dimensions: 16” x 2 7/16”
Material: cast stainless steel
Weight: 3.2

==> All Coleman Burners.

9991-132 Cooking Grids

Click for photos

Cast iron cooking grid for Coleman model 9991-132. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

==> All Coleman Cooking Grids.

9991-132 Heat Plates

Click for photos

Stainless steel Heat Tent for Coleman model 9991-132.

Part Number: COHP1
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 6 1/4”
Material: stainless steel
Weight: 1.45

==> All Coleman Heat Plates.

9991-132 Accessories

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

Click for photos

16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Material: chrome steel
Weight: 0.9

Click for photos

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

Click for photos

Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

==> All 9991-132 Accessories.
