GrillPro 236454 Grill Parts

Highest quality replacement parts for your GrillPro 236454 - Free USA shipping $49 or more* - No Sales Tax*

GrillPro 236454 owners manual and diagrams

Click the small images on the right to view GrillPro 236454 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

GrillPro 236454-445364633-PartsExpS1.gif

GrillPro 236454-445364633-PartsLstS1.gif

Replacement grill parts for GrillPro model: 236454

All of the parts we have for GrillPro 236454 are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for GrillPro grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct GrillPro 236454 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your GrillPro model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

236454 Burners

Click for photos

Genuine OEM GrillPro stainless steel burner for GrillPro model 236454.

Part Number: 22209-174
Dimensions: 16 3/8” x 1”
Material: Stainless steel
Weight: 0.5

==> All GrillPro Burners.

236454 Cooking Grids

Click for photos

Aftermarket reversible heavy cast iron cooking grid for GrillPro model 236454.

Sold individually
Number required varies, check your grill
Porcelain treated, flat matte finish
Pointed side is designed for perfect sear marks
Grooved side captures juices for continous basting

Fits: Broil King 500/625/750 series grills.

NOTE: This aftermarket part, made of the same materials as the original, is a perfect replacement for original part# 22005-281 but at a much lower cost.

Part Number: 22005-281-R
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 6 1/16”
Material: Cast iron
Weight: 5.0

==> All GrillPro Cooking Grids.

236454 Heat Plates

Click for photos

Stainless steel Flame Tamer for GrillPro model 236454. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0087
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 6”
Material: stainless steel
Weight: 1.0

HEAT SHIELD REGULATOR SILVER -- GPB for GrillPro model 236454.

Part Number: 338-C541
Weight: 1.0

==> All GrillPro Heat Plates.

236454 Knobs and Handles

Click for photos

Control knob.

Off position D-Value: 6 or 12 o'clock
Knob diameter: 2 1/8”
Socket diameter: 5/16”
Knob shaft: None

Part Number: 472-C501
Weight: 0.1

Click for photos

Genuine OEM GrillPro control knob bezel.

Part Number: 472-C500
Weight: 0.03

==> All GrillPro Knobs and Handles.

236454 Regulators and Hoses

Click for photos

Straight thru L.P regulator with 28” hose. Adequate to 90,000 BTU.

Part Number: HR-6B
Dimensions: 28
Weight: 1.50

==> All GrillPro Regulators and Hoses.

236454 Wheels and Castors

Click for photos

Wheel 6” plastic with 3/8” axle hole.

Part Number: 10892-608
Weight: 0.2

SHAFT WHEEL SILVER GPB

Special order part. Orders for this part may not ship for 4 to 12 weeks

Part Number: C15172S
Weight: 1.0

==> All GrillPro Wheels and Castors.

236454 Valves, Orifices, and Manifolds

Click for photos

Genuine OEM GrillPro valve assembly.

Special order part. Orders for this part may not ship for 4 to 12 weeks

Part Number: 440-C500
Weight: 1.9

==> All GrillPro Valves, Orifices, and Manifolds.

236454 Heat indicators and Meat Thermometers

Click for photos

Genuine OEM GrillPro Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

==> All GrillPro Heat indicators and Meat Thermometers.

236454 Miscellaneous Repair Parts

Click for photos

Hinge pin clip.

Part Number: S21233
Weight: 0.01

==> All GrillPro Miscellaneous Repair Parts.

236454 Cart Parts

Click for photos

COVER CONTROL ASSY SS GPB

Part Number: 194-C503
Weight: 1.0

==> All GrillPro Cart Parts.

236454 Accessories

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Click for photos

Aluminum foil grilling trays. Package of three.

Heavy duty aluminum foil
Re-usable
Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

==> All 236454 Accessories.
