BBQTEK GSC2418 Grill Parts

BBQ Grillware 4-Burner LP Gas Grill, Lowe's item# 164826

Highest quality replacement parts for your BBQTEK GSC2418 - Free USA shipping $49 or more* - No Sales Tax*

BBQTEK GSC2418 owners manual and diagrams

Click the small images on the right to view larger images of BBQTEK GSC2418 exploded parts diagrams, parts lists, and owners manuals.

BBQTEK GSC2418-4EE5468132-PartsExpS1.gif

Replacement BBQ grill parts for BBQTEK model: GSC2418

This page shows all of the parts we know fit model BBQTEK GSC2418. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for BBQTEK grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct BBQTEK GSC2418 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your BBQTEK model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

GSC2418 Burners

Click for photos

Stainless steel tube burner for BBQTEK model GSC2418. Does not have an electrode bracket attached. If your model needs the electrode bracket, see part number 12411.

Part Number: BBQT1
Dimensions: 16 1/2
Material: stainless steel
Weight: 0.5

Click for photos

Stainless steel tube burner for BBQTEK model GSC2418.

SS tube burner
Electrode mounting bracket (not all models use bracket)
Spider exclusion screen
Adjustable air shutter.

NOTE: Some earlier versions of this burner, which are no longer available, were a bit larger in diameter. Some models may not need the electrode tab.

Part Number: 12411
Dimensions: 16 1/2” x 1”
Material: stainless steel
Weight: 0.6

==> All BBQTEK Burners.

GSC2418 Burner Brackets and Carryovers

Click for photos

Stainless steel burner support bracket. Made in USA.

Part Number: CLA-MS0172
Dimensions: 21 1/4”
Material: stainless steel
Weight: 0.95

==> All BBQTEK Burner Brackets and Carryovers.

GSC2418 Cooking Grids

Click for photos

Cast Iron Cooking Grid - Brickman, BBQ Grill for BBQTEK model GSC2418.

Part Number: CG-101PCI
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 11 1/2”
Material: cast iron
Weight: 5.80

Click for photos

Cast iron cooking grids for BBQTEK model GSC2418. SET OF TWO (2) panels.

Porcelain treated, matte finish
Each panel measures 17 3/4” x 11 1/2”
Overall dimensions: 17 3/4” x 23”

Part Number: CG-101PCI-X2
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 23”
Material: cast iron
Weight: 11.6

Click for photos

Cast iron cooking grids for BBQTEK model GSC2418. SET OF THREE (3) panels.

Porcelain treated, matte finish
Each panel measures 17 3/4” x 11 1/2”
Overall dimensions: 17 3/4” x 34 1/2”

Part Number: CG-101PCI-X3
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 34 1/2”
Material: cast iron
Weight: 17.4

==> All BBQTEK Cooking Grids.

GSC2418 Heat Plates

Click for photos

Stainless steel heat plate for BBQTEK model GSC2418.

Part Number: BBQHP1
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 1/2”
Material: stainless steel
Weight: 0.7

==> All BBQTEK Heat Plates.

GSC2418 Igniter Components

Click for photos

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

==> All BBQTEK Igniter Components.

GSC2418 Knobs and Handles

Click for photos

Universal 2 5/16” knob.

Selectable D-Value
Selectable socket diameter - 6mm or 8mm.
Selectable shaft length - flush, 1/4”, or 1 5/8”. Shafts can also be trimmed to desired length.
Includes 6 shaft inserts and set screw.
Fits any grill with inside bezel diameter greater than 2 5/16” (the knob diameter).

Part Number: 02342
Dimensions: 2 5/16” x 2 5/16”
Material: plastic
Weight: 0.20

==> All BBQTEK Knobs and Handles.

GSC2418 Heat indicators and Meat Thermometers

Click for photos

Round heat indicator.

Single probe
3” diameter
Requires 3/8” mounting hole

Part Number: 00016
Dimensions: 3” x 3”
Weight: 0.2

==> All BBQTEK Heat indicators and Meat Thermometers.

GSC2418 Miscellaneous Repair Parts

Heat plate bracket, stainless steel. Made in USA

Part Number: CLA-MS0288
Dimensions: 23
Material: stainless steel
Weight: .75

==> All BBQTEK Miscellaneous Repair Parts.

GSC2418 Accessories

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All GSC2418 Accessories.
