Char-Griller 5072 Grill Parts

Char-Griller 5072

Char-Griller Dual Function 5072 Charcoal and 3-burner gas grill with side burner, Walmart #554587287

Highest quality replacement parts for your Char-Griller 5072 - Free USA shipping $49 or more* - No Sales Tax*

Char-Griller 5072 owners manual and diagrams

Diagrams & owners manual not available for grill model# 5072. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement gas grill parts for Char-Griller model: 5072

All of the parts we have for Char-Griller 5072 are shown on this page. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Char-Griller grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Char-Griller 5072 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Char-Griller model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

5072 Burners

CHGT1

Click for photos

Stainless steel tube burner with electrode-mounting bracket for Char-Griller model 5072.

Part Number: CHGT1
Dimensions: 20 1/8” x 1”
Material: stainless steel
Weight: 1.0

==> All Char-Griller Burners.

5072 Cooking Grids

CG-DUMMY

Cooking grid not known for Char-Griller model 5072. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Char-Griller cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0

==> All Char-Griller Cooking Grids.

5072 Heat Plates

CLA-TS0146-X3

Click for photos

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Char-Griller model 5072. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0146-X3
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 3 13/16”
Material: stainless steel
Weight: 2.4

CHGHP1

Click for photos

Stainless steel Flame Shield/heatplate for Char-Griller model 5072.

Part Number: CHGHP1
Dimension Front-to-Back: 18 15/16”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 1.0

==> All Char-Griller Heat Plates.

5072 Igniter Components

TS-IG3007

Click for photos

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007
Weight: 0.2

TS-IG4010

Click for photos

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

03333

Click for photos

Universal three-outlet battery powered push button ignitor.

1.5 volt
Has three (3) terminals (male spade connector)
Uses a single AA battery (not included)
03610 and 03620 wires are commonly used with this igniter (not included)
Requires 7/8” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03333
Dimensions: 2 9/16” x 2”
Weight: 0.5

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

IG-20B

Click for photos

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

900156 / IGEIB4-B

Click for photos

Battery powered push button igniter.

Has four (4) spade type male connectors.
Uses 1 AAA battery (not supplied)
Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B (Replaces Char-Griller 900156)
Weight: 0.3

==> All Char-Griller Igniter Components.

5072 Grease Trays

03509

Click for photos

Ash pan.

Part Number: 03509
Dimensions: 12 13/16” x 20 3/8”
Material: aluminized steel
Weight: 6.9

200163 / 200163-R

Click for photos

Stainless steel replacement catch pan (grease tray) preassembled and removable. Replaces OEM # 200163. Includes mini grease cup and cup hanger. Made in USA.

Part Number: 200163-R (Replaces Char-Griller 200163)
Dimensions: 10 1/8” x 25”
Material: stainless steel
Weight: 4.0

==> All Char-Griller Grease Trays.

5072 Heat indicators and Meat Thermometers

00015

Click for photos

Round heat indicator.

Single 1 5/8” probe
2 1/8” diameter
Requires 1/4” mounting hole

Part Number: 00015
Weight: 0.10

==> All Char-Griller Heat indicators and Meat Thermometers.

5072 Accessories

00150

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

40269

Click for photos

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.

Part Number: 40269
Material: stainless steel
Weight: 0.14

BRGG

Click for photos

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

RR-2

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

==> All 5072 Accessories.

BBQ Part Categories

Char-Griller model 5072 - Thursday, Sep 5 2024
