Charbroil Designer 463253905 Grill Parts

Charbroil logo



Charbroil 463253905

Char-Broil Designer Series Stainless 3-Burner LP gas BBQ grill with side burner



Highest quality replacement parts for your Charbroil Designer 463253905 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463253905 owners manual and diagrams
Diagrams & owners manual not available for grill model# 463253905. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement grill parts for the Charbroil Designer 463253905
This page shows all of the parts we know fit model Charbroil 463253905. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 463253905 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463253905 Burners

80000023 / CIDCH
Click for photos
Cast iron burner for Charbroil model 463253905.

Part Number: CIDCH (Replaces Charbroil 80000023)
Dimensions: 13 13/16” x 2 1/4”
Material: cast iron
Weight: 3.0

$32.98

Qty


==> All Charbroil Burners.






463253905 Cooking Grids

CLA52932S
Click for photos
Heavy duty stainless steel cooking grid for Charbroil model 463253905.
  • 304 commercial grade stainless
  • Solid 5/16” stainless rods
  • Sold individually
  • Made in USA.


Part Number: CLA52932S
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 12 1/4”
Material: solid 304 stainless steel rod
Weight: 6.4

$54.77

Qty


66124-1PC
Click for photos
Cast iron cooking grid for Charbroil model 463253905. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

$37.52

Qty


CG-74P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463253905. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

$43.61

Qty


10225-T536
Click for photos
cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 463253905.
  • Sold individually.
  • Number required varies.
  • Porcelain enameled cast iron, flat matte finish.


Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

$56.52

Qty


80000293 / CG-63P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463253905. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-63P-CI (Replaces Charbroil 80000293)
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 7.15

$55.11

Qty


CG-74P-CI-X3
Click for photos
Cast iron cooking grids for Charbroil model 463253905. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 16 7/8” x 8 1/4”
  • Overall dimensions: 16 7/8 x 23 3/4”


Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

$113.25

Qty


==> All Charbroil Cooking Grids.






463253905 Heat Plates

CLA-TS0143-X3
Click for photos
SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Charbroil model 463253905. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0143-X3
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 4 3/16”
Material: stainless steel
Weight: 2.4

$49.83

Qty


80000855 / CBHP4
Click for photos
Stainless steel heat plate/Flame Tamer for Charbroil model 463253905.


Part Number: CBHP4 (Replaces Charbroil 80000855)
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 4 5/16”
Material: stainless steel
Weight: 0.7

$33.80
SALE  $18.13
Qty


==> All Charbroil Heat Plates.






463253905 Knobs and Handles

01800
Click for photos
Universal black control knob. Counter-clockwise bezel.
  • Off position D-Value: Selectable
  • Knob diameter: 2 1/16”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

$6.55

Qty


80000035 / 01700
Click for photos
Black control knob for Fire Magic Custom, Regal, and Gourmet grills.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

$10.84

Qty


==> All Charbroil Knobs and Handles.






463253905 Heat indicators and Meat Thermometers

80000096 / GG-TG4
Click for photos
Round temperature gauge. Fits MHP Grills JNR, WNK, TJK, GJK, WRG, TRG.
  • 2 1/2” diameter.
  • Single prob
  • Requires 3/8” mounting hole


    Part Number: GG-TG4 (Replaces Charbroil 80000096)
    Weight: 0.15

$21.23

Qty


GG-TG3
Click for photos
Rectangular heat indicator for old style MHP grills that has two pegs and a center probe to mount through the casting. It was used on older JNR and WNK grills. We are not sure when MHP changed to the newer heat indicator GG-TG4 that has one larger peg to mount. The GG-TG3 needs two small holes for mounting and one hole in the center for the probe.

Part Number: GG-TG3
Dimensions: 2 5/8” x 2 1/4”
Weight: 0.15

$11.37

Qty


==> All Charbroil Heat indicators and Meat Thermometers.






463253905 Accessories

FS-1
Click for photos
Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

$17.27

Qty


WB-3
18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

$12.50

Qty


==> All 463253905 Accessories.
