Charbroil 463723912 Grill Parts

Stainless steel main burner for Charbroil model 463723912.

Part Number: CBP12 (Replaces Charbroil G314-0700-W1A)
Dimensions: 11 1/2
Material: stainless steel
Weight: 1.0

Stainless steel cross-over burner

Part Number: 05599 (Replaces Charbroil G314-0307-W1)
Dimensions: 8 3/4” x 0 3/4”
Material: stainless steel
Weight: 0.2

Porcelain steel cooking grids for Charbroil model 463723912. Porcelain enameled, glossy finish. Sold as a set of two (2).

Part Number: 52672 (Replaces Charbroil G314-0304-W1)
Dimension Front-to-Back: 13 1/2”
Dimension Side-to-Side: 25 1/2”
Material: porcelain steel wire
Weight: 5.5

Stainless steel heat plate for Charbroil model 463723912.

Part Number: CBHP11 (Replaces Charbroil G314-0303-W1)
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 4 1/4”
Material: stainless steel
Weight: 1.0

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Snap In Piezo Ignitor. Fits Weber Genesis Silver A,B,C and Newer Spirit E310 & E320.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-9B
Weight: 0.2

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

Push-Button self-grounding piezo spark generator; requiers 3/4” mounting hole. Primary connector is a round male connector, so connecting wire needs to be female round connector. If needed, see part# 03199C for a short adapter wire that converts flat female spade connectors to female round. Secondary connector is a flat male spade connector used to conduct spark to a secondary electrode, such as a side burner, or used as a ground in some applications. See ground wire part# 03620. For more information, see our article Ignition 101.

Part Number: 03120 (Replaces Charbroil G206-0301-W1)
Weight: 0.1

Burner mounted electrode for use with 15591 and 15491 burners.

• 39” wire with female spade connector
• Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04430 (Replaces Charbroil G314-0003-W1)
Material: ceramic
Weight: 0.1

16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Material: chrome steel
Weight: 0.9

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2
