Charbroil Quickset Traditional 463741304 Grill Parts

Charbroil logo



Charbroil 463741304

Char-Broil Quickset Traditional 7000 series 2-burner LP gas grill



Highest quality replacement parts for your Charbroil Quickset Traditional 463741304 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463741304 owners manual and diagrams
Diagrams & owners manual not available for grill model# 463741304. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement BBQ grill parts for Charbroil Quickset Traditional 463741304
This page shows all of the parts we know fit model Charbroil 463741304. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 463741304 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463741304 Venturis

SG-B
Click for photos
Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

$7.62

Qty


==> All Charbroil Venturis.






463741304 Cooking Grids

10225-T406
Click for photos
ONE PANEL for Charbroil model 463741304. Genuine OEM cast iron cooking grid, single panel.
  • Sold individually
  • Number required varies
  • Porcelain treated, flat matte finish.


Part Number: 10225-T406
Dimension Front-to-Back: 14 1/8”
Dimension Side-to-Side: 12 1/4”
Material: Cast iron
Weight: 4.75

$43.93

Qty


4152739 / 55701-SS
Click for photos
Premium quality stainless steel cooking grid for Charbroil model 463741304. Far superior to the porcelain coated steel grids it replaces.
  • Made in USA
  • 304 commercial grade stainless steel
  • Solid .225 diameter stainless rods
  • Sold individually


Part Number: 55701-SS (Replaces Charbroil 4152739)
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 24”
Material: stainless steel
Weight: 5.0

$83.82

Qty


4152739 / CG-45SS
Click for photos
Commercial grade 304 stainless steel cooking grid with 1/4” diameter rods for Charbroil model 463741304. Made in USA.

Part Number: CG-45SS (Replaces Charbroil 4152739)
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 24”
Material: Stainless steel
Weight: 6.0

$83.82

Qty


==> All Charbroil Cooking Grids.






463741304 Rock/Briquette Grates

BG-38
Click for photos
Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-38
Dimension Front-to-Back: 10 3/4”
Dimension Side-to-Side: 22 1/4”
Material: carbon steel
Weight: 3.5

$27.91

Qty


==> All Charbroil Rock/Briquette Grates.






463741304 Heat Plates

4500290 / CLA-TS0024
Click for photos
Stainless steel VapoRiser Bar (V-Bar) for Charbroil model 463741304. Sold individually, number required varies. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0024 (Replaces Charbroil 4500290)
Dimension Front-to-Back: 5 1/2”
Dimension Side-to-Side: 23 3/8”
Material: stainless steel
Weight: 2.3

$47.99

Qty


==> All Charbroil Heat Plates.






463741304 Igniter Components

03199C
Click for photos
Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03199C
Weight: 0.05

$4.37

Qty


IG-28B
Click for photos
Collector Box and electrode for Charbroil top ported TBBC & TLBBC burners.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-28B
Weight: 0.2

$9.60

Qty


10342-T14
Click for photos
21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

$4.32

Qty


4153713 / UP-4B
Click for photos
Universal push-button igniter. Round male connector. Includes locking nut.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: UP-4B (Replaces Charbroil 4153713)
Weight: 0.3

$6.37

Qty


IG-7B
Click for photos
20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-7B
Weight: 0.02

$4.75

Qty


IG-18B
Click for photos
20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-18B
Weight: 0.03

$4.93

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


==> All Charbroil Igniter Components.






463741304 Warming Racks

4152124 / 02124
Click for photos
Chrome steel bottom warming rack for Charbroil 7000 series U-burner grills.

Part Number: 02124 (Replaces Charbroil 4152124)
Dimensions: 23 1/2” x 10 1/2”
Material: chrome steel wire
Weight: 1.10

$30.51

Qty


==> All Charbroil Warming Racks.






463741304 Accessories

BQ-5
Click for photos
Durable 2 5/16” round briquettes
  • Self-cleaning
  • Control flare-ups while holding an even heat pattern.
  • About 53 pieces, covers approximately 275 sq. inches.
  • Fits all gas grills


Part Number: BQ-5
Weight: 7.2

$31.19

Qty


45887
Click for photos
Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

$24.48

Qty


SSST
Click for photos
Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

$24.00
SALE  $27.05
Qty


SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90

Qty


00030
Click for photos
EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

$7.60

Qty


WB-7
Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

$5.96

Qty


==> All 463741304 Accessories.




BBQ Part Categories


























Charbroil gas grill 463741304 - Sunday, Jan 26 2025

Return to Charbroil grills main page



More Charbroil grill models we have parts for
4617000 | 4617003 | 4617017 | 4617018 | 4617019 | 4617064 | 4617100 | 4617120 | 4617136 | 4617164 | 4617184 | 4617185 | 4617216 | 4617222 | 4617238 | 461731603 | 461732103 | 461733803 | 461740304 | 461740404 | 461740405 | 461742204 | 4618032 | 4618034 | 4618040 | 4618041 | 4618043 | 4618051 | 4618088 | 4618134 | 4618155 | 4618166 | 461821707 | 4618226 | 4618238 | 4618239 | 4618246 | 4618259 | 4618296 | 461831103 | 461832103 | 461833803 | 461833903 | 461834603 | 461835603 | 461837603 | 461841204 | 461846104 | 4619041 | 4619141 | Complete list of Charbroil grill models...



*Orders for Charbroil Quickset Traditional grill model 463741304 $49 and over ship free to the lower 48 states.
See shipping policy below for more info.
