Charbroil Quickset Traditional 463761106 Grill Parts

Charbroil 463761106

Char-Broil Quickset Traditional 7000 series 2-burner LP gas grill with side burner

Highest quality replacement parts for your Charbroil Quickset Traditional 463761106 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 463761106 owners manual and diagrams

Diagrams & owners manual not available for grill model# 463761106. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement BBQ grill parts for Charbroil Quickset Traditional 463761106

On this page you'll find all of the parts that fit model Charbroil 463761106. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463761106 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

463761106 Venturis

SG-B

Click for photos

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

==> All Charbroil Venturis.

463761106 Cooking Grids

10225-T406

Click for photos

ONE PANEL for Charbroil model 463761106. Genuine OEM cast iron cooking grid, single panel.

Sold individually
Number required varies
Porcelain treated, flat matte finish.

Part Number: 10225-T406
Dimension Front-to-Back: 14 1/8”
Dimension Side-to-Side: 12 1/4”
Material: Cast iron
Weight: 4.75

4152739 / 55701-SS

Click for photos

Premium quality stainless steel cooking grid for Charbroil model 463761106. Far superior to the porcelain coated steel grids it replaces.

Made in USA
304 commercial grade stainless steel
Solid .225 diameter stainless rods
Sold individually

Part Number: 55701-SS (Replaces Charbroil 4152739)
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 24”
Material: stainless steel
Weight: 5.0

4152739 / CG-45SS

Click for photos

Commercial grade 304 stainless steel cooking grid with 1/4” diameter rods for Charbroil model 463761106. Made in USA.

Part Number: CG-45SS (Replaces Charbroil 4152739)
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 24”
Material: Stainless steel
Weight: 6.0

==> All Charbroil Cooking Grids.

463761106 Heat Plates

4500290 / CLA-TS0024

Click for photos

Stainless steel VapoRiser Bar (V-Bar) for Charbroil model 463761106. Sold individually, number required varies. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0024 (Replaces Charbroil 4500290)
Dimension Front-to-Back: 5 1/2”
Dimension Side-to-Side: 23 3/8”
Material: stainless steel
Weight: 2.3

==> All Charbroil Heat Plates.

463761106 Igniter Components

03199C

Click for photos

Universal 2 3/4” adaptor wire with a round female end and a male spade end that has a protective cover.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03199C
Weight: 0.05

IG-28B

Click for photos

Collector Box and electrode for Charbroil top ported TBBC & TLBBC burners.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-28B
Weight: 0.2

10342-T14

Click for photos

21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

5156113 / 03120

Click for photos

Push-Button self-grounding piezo spark generator; requiers 3/4” mounting hole. Primary connector is a round male connector, so connecting wire needs to be female round connector. If needed, see part# 03199C for a short adapter wire that converts flat female spade connectors to female round. Secondary connector is a flat male spade connector used to conduct spark to a secondary electrode, such as a side burner, or used as a ground in some applications. See ground wire part# 03620. For more information, see our article Ignition 101.

Part Number: 03120 (Replaces Charbroil 5156113)
Weight: 0.1

IG-7B

Click for photos

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

IG-18B

Click for photos

20” igniter wire with two (2) female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-18B
Weight: 0.03

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

UP-9B

Click for photos

Snap In Piezo Ignitor. Fits Weber Genesis Silver A,B,C and Newer Spirit E310 & E320.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: UP-9B
Weight: 0.2

==> All Charbroil Igniter Components.

463761106 Warming Racks

4152124 / 02124

Click for photos

Chrome steel bottom warming rack for Charbroil 7000 series U-burner grills.

Part Number: 02124 (Replaces Charbroil 4152124)
Dimensions: 23 1/2” x 10 1/2”
Material: chrome steel wire
Weight: 1.10

==> All Charbroil Warming Racks.

463761106 Accessories

BB-5

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

VTC-B

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All 463761106 Accessories.
