Charbroil Performance 466453605 Grill Parts

Char-Broil Performance Series 3-Burner LP gas grill with side burner

Highest quality replacement parts for your Charbroil Performance 466453605 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 466453605 owners manual and diagrams

Diagrams & owners manual not available for grill model# 466453605. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts to fit Charbroil Performance 466453605

All of the parts we have for Charbroil 466453605 are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 466453605 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

466453605 Burners

Click for photos

Cast iron burner for Charbroil Performance and Advantage series grills for Charbroil model 466453605. Interchangable with the stainless steel version.

Part Number: CBP1-CI
Dimensions: 13 3/4” x 3 3/8”
Material: cast iron
Weight: 6.0

Click for photos

Stainless steel burner for Charbroil Performance and Advantage series grills for Charbroil model 466453605. Interchangable with the cast iron version.

Part Number: CBP1 (Replaces Charbroil 7000083)
Dimensions: 13 3/4” x 3 1/4”
Material: stainless steel
Weight: 2.0

==> All Charbroil Burners.

466453605 Burner Brackets and Carryovers

Click for photos

Burner support bracket with gas carryover tubes. For 3-burner grills.

Part Number: CBBR2 (Replaces Charbroil 7000279)
Dimensions: 19 5/16
Material: stainless steel
Weight: .35

==> All Charbroil Burner Brackets and Carryovers.

466453605 Cooking Grids

Click for photos

Cast iron cooking grid for Charbroil model 466453605. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-62P-CI (Replaces Charbroil 7000029)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 7 7/8”
Material: cast iron
Weight: 4.75

Click for photos

Cast iron cooking grid for Charbroil model 466453605. Porcelain treated, matte finish. Sold individually, number required varies by grill model

Part Number: CG-61P-CI (Replaces Charbroil 7000030)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 12”
Material: cast iron
Weight: 6.45

==> All Charbroil Cooking Grids.

466453605 Heat Plates

Click for photos

SET OF THREE/3 PACK Stainless steel heat plate for Charbroil model 466453605. Made in USA.

Note: Not identical to original, but a fully functional replacement.

Note: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0144-X3
Dimension Front-to-Back: 11 3/4”
Dimension Side-to-Side: 5 9/16”
Material: stainless steel
Weight: 1.8

Click for photos

Stainless steel VapoRiser Tent for Charbroil model 466453605. Fully functional replacement without the louvered slots.

Part Number: CBHP1 (Replaces Charbroil 7000381)
Dimension Front-to-Back: 11 3/4”
Dimension Side-to-Side: 5 5/8”
Material: stainless steel
Weight: 0.7

==> All Charbroil Heat Plates.

466453605 Igniter Components

Click for photos

Ceramic electrode for use with CBP1-CI cast iron burner.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-24B
Weight: 0.3

==> All Charbroil Igniter Components.

466453605 Heat indicators and Meat Thermometers

Click for photos

Round heat indicator.

Single probe
1 13/16” diameter
Requires 3/8” mounting hole

Part Number: 00018 (Replaces Charbroil 4157171)
Dimensions: 1 13/16” x 1 13/16”
Weight: 0.1

==> All Charbroil Heat indicators and Meat Thermometers.

466453605 Accessories

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Click for photos

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.

Part Number: 40269
Material: stainless steel
Weight: 0.14

Click for photos

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

==> All 466453605 Accessories.
