Coleman 5400 9992-141 Grill Parts

Coleman 5400 LP Gas Series

Highest quality replacement parts for your Coleman 5400 9992-141 - Free USA shipping $49 or more* - No Sales Tax*

Coleman 9992-141 owners manual and diagrams

Click the small images on the right to view Coleman 9992-141 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Coleman 9992-141-30004486831-PartsExpS1.gif

Coleman 9992-141-30004486831-PartsLstS1.gif

Replacement grill parts to fit Coleman 5400 9992-141

This page shows all of the parts we know fit model Coleman 9992-141. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Coleman grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Coleman 9992-141 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Coleman model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

9992-141 Burners

Click for photos

Cast stainless steel burner for Coleman model 9992-141. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design.

NOTE: This burner is equiped with an air intake adjustable control shutter (not shown in photos) and with an air intake control screw for regulating the air/gas mixture into the burner. Natural gas applications require more air (more open screw) than lquid propane (LP). If necessary, adjust screw to get a yellow-tipped blue flame.

Part Number: 23301-CSS
Dimensions: 16” x 2 7/16”
Material: cast stainless steel
Weight: 3.2

Click for photos

Cast iron burner for Coleman model 9992-141.

Part Number: CIT
Dimensions: 15 3/4” x 2 7/8”
Material: cast iron
Weight: 4.2

==> All Coleman Burners.

9992-141 Cooking Grids

Click for photos

Cast iron cooking grid for Coleman model 9992-141. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

==> All Coleman Cooking Grids.

9992-141 Heat Plates

Click for photos

Stainless steel Heat Tent for Coleman model 9992-141.

Part Number: COHP1
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 6 1/4”
Material: stainless steel
Weight: 1.45

==> All Coleman Heat Plates.

9992-141 Accessories

Click for photos

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

==> All 9992-141 Accessories.
