Ducane 7200R Grill Parts

Right-side stainless steel burners for Ducane model 7200R.
NOTE: For models 7200 and 7200R, the burners are reversed such that this is the left-side burner for those models.

Part Number: DUC-3RSS (Replaces Ducane 31200015)
Dimensions: 18 1/4” x 9 1/4”
Material: 304 Stainless steel
Weight: 4.0

Left-side stainless steel burner for Ducane model 7200R.
NOTE: For models 7200 and 7200R, the burners are reversed such that this is the right-side burner for those models.

Part Number: DUC-3LSS (Replaces Ducane 31200016)
Dimensions: 18 1/4” x 9 1/4”
Material: 304 Stainless steel
Weight: 4.0

U burner support bracket for Ducane model 7200R. Replaces OEM# 20175501. Sold indivually. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0057
Material: stainless steel
Weight: 0.05

C burner support bracket for Ducane model 7200R. Replaces OEM# G4162359. Sold indivually. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-MS0058
Material: stainless steel
Weight: 0.05

Right-side stainless steel burner kit for Ducane model 7200R. Includes 165L1 right-side burner, 03758 electrode, wire, and collector box.
NOTE: For models 7200 and 7200R, the burners are reversed such that this is the right-side burner for those models.

Part Number: 16511
Dimensions: 18 1/4” x 8 7/8”
Material: stainless steel
Weight: 1.7

Left-side stainless steel burner kit for Ducane model 7200R. Includes 165R1 left-side burner, 03758 electrode, wire, and collector box.
NOTE: For models 7200 and 7200R, the burners are reversed such that this is the left-side burner for those models.

Part Number: 16521
Dimensions: 18 1/4” x 8 7/8”
Material: stainless steel
Weight: 1.7

Stainless steel Sear Grid set for Ducane model 7200R. Replaces Ducane OEM part 20172305.

The stainless steel SEAR GRID is a 2-piece die formed part with domed runners. Each runner traps and collects the heat of the briquettes thus making your grill 30% more effective than other cooking grids. The trapped heat within each runner produces wide sear marks on the meat, thus sealing in the meat’s juices.

The SEAR GRID is made of a high quality stainless steel. Due to the heat of cooking, a discoloration of the SEAR GRID is normal and will not affect the SEAR GRID in any manner.


Part Number: 565S2 (Replaces Ducane 20172305)
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 24 1/2”
Material: stamped stainless steel
Weight: 6.0

20172205 Ducane Pyromid® briquettes. Bag of 90 high quality pyromid-shaped, flat-top ceramic pieces. These are the same OEM factory briquettes that came with your new Ducane grill

Fits Ducane 1605 and 7200 series grills, and all models using La-Va-Grate part# 20172508.

Part Number: 20172205
Dimension Front-to-Back: 2”
Dimension Side-to-Side: 2”
Material: ceramic
Weight: 12.8

20172508-R LA-VA-GRATE. Stainless steel rack for supporting lava rock.

Fits 1600, 1605, and 7200 series grill heads by Ducane.

• Replaces original OEM part# 20172508
• Commercial grade stainless steel

All Ducane grills are equipped with a patented, high temp stainless steel Lava Grate. This grate-like device is installed above the burner(s) and supports the briquettes. The Lava Grate is constructed of two layers of offset “V”-shaped runners. When properly installed, the bottom of the “V”-shaped runners must point toward the burner.

Part Number: 20172508-R (Replaces Ducane 20172508)
Dimension Front-to-Back: 18 3/16”
Dimension Side-to-Side: 24 5/16”
Material: stainless steel
Weight: 6.9

20172508-KIT LA-VA-GRATE and Pyromid® Briquettes.

Kit includes:
• 20172508-R Stainless steel Lava Grate for supporting ceramic briquettes and lava rock.

  Fits 1605 and 7200 series grills by Ducane.

• 20172205 Ducane Pyromid® briquettes. Bag of 90 high quality pyromid-shaped, flat-top ceramic pieces. These are the same OEM factory briquettes that came with your new Ducane grill

Part Number: 20172508-KIT
Dimension Front-to-Back: 18 3/16”
Dimension Side-to-Side: 24 5/16”
Material: stainless steel
Weight: 19.7

Heat Plate/ Flame Tamer not known for Ducane model 7200R. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

Igniter electrode assembly to fit Ducane grills. Use on Duc-1 and Duc-2 buners. INcludes collector box, ceramic electrode, and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-9B (Replaces Ducane 31200013)
Weight: 0.3

21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

Brass hood orifice with #72 starter hole and 1/8” x 22 threading for use with valves 37700, 37800, and 38800. Must be drilled to proper drill size.

If you would like us to drill the orifice(s) for you, there is a single $15 fee for this service, which will be added to the order when processed. Please tell us the number of burners in your grill and the total BTUs of your grill (less side burner and rotisserie burner, if any). BTU rating information can usually be found on the grill's CSA certification tag, located somewhere on the grill. Please furnish this, along with any other information you deem relevant, in the Message to CLA box during checkout.

Part Number: 37900
Dimensions: 0 3/4” x 0 1/2”
Material: brass
Weight: 0.1

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.


Part Number: 40269
Material: stainless steel
Weight: 0.14
