Falcon GF430-329-EI Grill Parts

Cast iron burner and venturi assembly kit for Falcon model GF430-329-EI. Comes with all necessary gaskets and screws.

Part Number: 20502-72401
Dimensions: 15 7/8” x 8”
Material: cast iron
Weight: 8.0

cast iron burner head for Falcon model GF430-329-EI.

Part Number: 20502
Dimensions: 15 7/8” x 8”
Material: cast iron
Weight: 7.7

Stainless steel burner and venturi assembly kit for Falcon model GF430-329-EI. Contains one standard EDSB SS H burner and two (2) V-12 stainless steel single adjustable venturi..

Part Number: EDSB+V-11
Dimensions: 7 1/4” x 15 1/2”
Material: stainless steel
Weight: 2.0

Standard stainless steel burner with adjustable legs for Falcon model GF430-329-EI. Comes with gasket and scews.

Part Number: EDSB
Dimensions: 7 1/4” x 15 1/2”
Material: stainless steel
Weight: 1.5

Deluxe stainless steel twin-venturi burner and venturi assembly for Falcon model GF430-329-EI. Includes:

• DSB stainless steel H burner.
• Deluxe burners have a special spot-welded mounting bracket for optional IG-5B universal tongue-style collector box and electrode. The IG-5B can be used in applications where the factory ignition system is irrepairable, non existant, or otherwise unusable.
• Two (2) V-11 flexible adjustable stainless steel single venturi.
• Venturi gasket and mounting nuts (venturi mounts with nuts and bolts, not screws).
• 5 year MHP limited warranty.
• Click here for features of MHP deluxe SS burner.

Part Number: DSB+V-11
Dimensions: 8 1/8” x 16”
Material: stainless steel
Weight: 2.0

Deluxe stainless steel twin-venturi burner for Falcon model GF430-329-EI. Includes:

• DSB stainless steel H burner (venturi not included).
• Deluxe burners have a special spot-welded mounting bracket for optional IG-5B universal tongue-style collector box and electrode. The IG-5B can be used in applications where the factory ignition system is irrepairable, non existant, or otherwise unusable.
• Venturi gasket and mounting nuts (venturi mounts with nuts and bolts, not screws).
• 5 year MHP limited warranty.
• Click here for features of MHP deluxe SS burner.

Part Number: DSB
Dimensions: 8 1/8” x 16”
Material: stainless steel
Weight: 1.5

two venturi gaskets with screws

Part Number: 00400
Dimensions: 3 1/16” x 1 1/4”
Weight: 0.05

Universal stainless venturi flexible and adjustable from 8” to 11” and sold individually. Used to replace venturis for virtually any grill model for which no exact fit venturi is available. Gasket & screws not included, see part numbers 00400 or SHK4.

Part Number: 72401
Dimensions: 7 1/2” x 11”
Material: zinc plated steel
Weight: 0.3

Stainless steel single venturi, sold individually. Flexible and adjustable from 5.5” to 8”. Gasket & screws not included, see part # SHK4.

Part Number: V-11
Dimensions: 7
Material: stainless steel
Weight: .3

Single Gasket Kit Economy Burners

Part Number: SHK4
Weight: 0.01

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

Porcelain steel cooking grid for Falcon model GF430-329-EI. Porcelain enameled, glossy finish. Sold individually.

Part Number: 54501
Dimension Front-to-Back: 13”
Dimension Side-to-Side: 19”
Material: porcelain steel wire
Weight: 4.6

1-piece porcelain coated steel rod cooking grid for Falcon model GF430-329-EI.

Part Number: CG-11P
Dimension Front-to-Back: 13 1/16”
Dimension Side-to-Side: 19 5/8”
Material: Porcelain steel
Weight: 4.6

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-4
Dimension Front-to-Back: 11 5/8”
Dimension Side-to-Side: 19”
Material: Carbon steel
Weight: 2.7

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

Universal adapter wire with male round and female spade connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03751
Weight: 0.05

Tongue style collector box for burner mounted applications. Includes preinstalled electrode with round female connector end and 20” wire. Fits on all of our Deluxe stainless H burners (LB, SB, DLB, DSB) using special mounting bracket on these burners. Will not fit on cast iron burners (see part IG-15B for cast iron burner applications).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-5B
Weight: 0.3

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-15B
Weight: 0.3

Brass spud orifice with 5/16” x 32 thread size. Has #70 starter hole. Must be drilled to proper drill size.

If you would like us to drill the orifice(s) for you, there is a single $15 fee for this service, which will be added to the order when processed. Please tell us the number of burners in your grill and the total BTUs of your grill (less side burner and rotisserie burner, if any). BTU rating information can usually be found on the grill's CSA certification tag, located somewhere on the grill. Please furnish this, along with any other information you deem relevant, in the Message to CLA box during checkout.

Part Number: 31600
Dimensions: 0 3/8” x 0 7/16”
Material: brass
Weight: 0.01

Dual brass LP valve assembly. Includes left and right control valves and valve manifold. Fits Arkla up-front control grills and others requiring 45 degree angle valves.

• For use with LP gas
• Includes two orifices drilled to #57 drill size
• Includes pre-assembled 45 degree angle fitting, not shown in photo

Part Number: VLV-28
Material: brass
Weight: 1.1

Durable 2 5/16” round briquettes

• Self-cleaning
• Control flare-ups while holding an even heat pattern.
• About 53 pieces, covers approximately 275 sq. inches.
• Fits all gas grills

Part Number: BQ-5
Weight: 7.2

Ultimate ceramic grill bricks. 18 ceramic bricks covers 165 sq. inches. Designed to replace existing lava rock and ceramic briquettes.

• Self cleaning
• Reduces flare-ups
• Eliminates cold spots
• Lasts longer
• Stays hotter longer
• Each brick measures 3” x 3” x3/8”

Part Number: 43118
Weight: 2.7

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

8” Plastic grill brush with scraper.

Part Number: 77330
Weight: 0.3
