Fiesta ET34567 Grill Parts

Fiesta logo



Fiesta ET34567



Highest quality replacement parts for your Fiesta ET34567 - Free USA shipping $49 or more* - No Sales Tax*



Fiesta ET34567 owners manual and diagrams
Click the small images on the right to view Fiesta ET34567 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Fiesta ET34567-4CC5643232-PartsExpS1.gif  Fiesta ET34567-4CC5643232-PartsLstS1.gif

Replacement gas grill parts for Fiesta model: ET34567
On this page you'll find all of the parts that fit model Fiesta ET34567. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Fiesta grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Fiesta ET34567 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Fiesta model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



ET34567 Burners

SM202A-12 / 19202-79202
Click for photos
Stainless steel burner and venturi assembly kit for Fiesta model ET34567. Comes with all necessary gaskets and screws.

Part Number: 19202-79202 (Replaces Fiesta SM202A-12)
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 3.5

$80.29

Qty


19202
Click for photos
Stainless steel H burner for Fiesta model ET34567. Burner consists of two pieces, which are held together by the venturi.

Part Number: 19202
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 2.4

$65.76

Qty


==> All Fiesta Burners.






ET34567 Venturis

79202
Click for photos
L-shaped twin venturi. Includes all necessary gaskets and screws/nuts.

Part Number: 79202
Dimensions: 4 1/2” x 2 7/8”
Material: zinc plated steel
Weight: 0.8

$20.09

Qty


SG-B
Click for photos
Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

$7.62

Qty


==> All Fiesta Venturis.






ET34567 Cooking Grids

CG-DUMMY
Cooking grid not known for Fiesta model ET34567. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Fiesta cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0
==> All Fiesta Cooking Grids.






ET34567 Rock/Briquette Grates

BG-41
Click for photos
Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-41
Dimension Front-to-Back: 12”
Dimension Side-to-Side: 19”
Material: carbon steel
Weight: 4.1

$24.91

Qty


==> All Fiesta Rock/Briquette Grates.






ET34567 Heat Plates

CLA-TS0397
Click for photos
Stainless steel smart bar replacement for SP55-9 for Fiesta model ET34567.

Note: This is also a replacement for part SP24-9G, which has been discontinued. There is a difference in air hole alignment.

Part Number: CLA-TS0397
Dimension Front-to-Back: 20 3/4”
Dimension Side-to-Side: 10 1/2”
Material: stainless steel
Weight: 2.65

$67.98

Qty


==> All Fiesta Heat Plates.






ET34567 Igniter Components

IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


IG-15B
Click for photos
Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-15B
Weight: 0.3

$14.41

Qty


==> All Fiesta Igniter Components.






ET34567 Knobs and Handles

SP7-7
Click for photos
Genuine OEM Fiesta control knob.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2”
  • Socket diameter: 5/16”
  • Knob shaft: None (flat)


Part Number: SP7-7
Weight: 0.1

$5.15

Qty


SP9-7
Click for photos
Side burner knob.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2 3/16”
  • Socket diameter: 5/16”
  • Knob shaft: 1/8”


Part Number: SP9-7
Weight: 0.1

$5.15

Qty


==> All Fiesta Knobs and Handles.






ET34567 Wheels and Castors

Small locking caster with a slide-on mounting stud that is 5/16” in diameter. The caster wheel diameter is 1 1/2”.

Part Number: SP6-22
Weight: .10

$5.02

Qty


==> All Fiesta Wheels and Castors.






ET34567 Heat indicators and Meat Thermometers

SP23A-30
Click for photos
LOGO GUAGE FIESTA A/T LID

Part Number: SP23A-30
Weight: 0.5

$5.08

Qty


==> All Fiesta Heat indicators and Meat Thermometers.






ET34567 Accessories

BQ-5
Click for photos
Durable 2 5/16” round briquettes
  • Self-cleaning
  • Control flare-ups while holding an even heat pattern.
  • About 53 pieces, covers approximately 275 sq. inches.
  • Fits all gas grills


Part Number: BQ-5
Weight: 7.2

$31.19

Qty


45887
Click for photos
Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

$24.48

Qty


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$8.84

Qty


VTC-B
Click for photos
Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

$4.93

Qty


==> All ET34567 Accessories.
