Jenn-Air JA480 Grill Parts

Highest quality replacement parts for your Jenn-Air JA480 - Free USA shipping $49 or more* - No Sales Tax*

Jenn-Air JA480 owners manual and diagrams

Click the small images on the right to view Jenn-Air JA480 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts to fit Jenn-Air model: JA480

On this page you'll find all of the parts that fit model Jenn-Air JA480. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Jenn-Air grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Jenn-Air JA480 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Jenn-Air model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

JA480 Burners

Click for photos

Commercial premium grade stainless steel burner for Jenn-Air model JA480.

Part Number: VTB1 (Replaces Jenn-Air 50000835)
Dimensions: 17
Material: stainless steel
Weight: 1.0

Click for photos

Burner mounting plate for Jenn-Air model JA480. This part is used to reinforce the front grill housing so the burner can be mounted to the grill. In some cases, the grill housing has rusted or corroded such that the burner cannot be properly mounted to the front of the grill.

Sold individually, number required varies. Use one per burner.
Includes mounting bolt and nut
Includes extra holes for mounting to grill, if necessary.
Comes with complete installation instructions.

For models:

CF9080/85/86
VCS300/3500/35BI/4000/4005/5000/5005/5010/50BI
VCS3507/4007/5007/3507BI/5007BI

Made in USA

Part Number: CLA-MS0227
Dimensions: 3 3/4” x 4 15/16”
Material: stainless steel
Weight: 0.11

Click for photos

Premium grade stainless steel
Includes gasket and mounting screw
Comes with complete installation instructions
Sold individually.

For models:

CF9080/85/86
VCS300/3500/35BI/4000/4005/5000/5005/5010/50BI
VCS3507/4007/5007/3507BI/5007BI

Part Number: 03501
Dimensions: 3 3/4” x 4”
Material: stainless steel
Weight: 0.16

==> All Jenn-Air Burners.

JA480 Cooking Grids

Click for photos

Cast iron cooking grid for Jenn-Air model JA480. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-59P-CI (Replaces Jenn-Air 50001226)
Dimension Front-to-Back: 16 3/8”
Dimension Side-to-Side: 9 1/4”
Material: cast iron
Weight: 5.45

==> All Jenn-Air Cooking Grids.

JA480 Heat Plates

Click for photos

Stainless steel Flame Tamer for Jenn-Air model JA480. Sold individually, number required varies. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0016 (Replaces Jenn-Air 50000777)
Dimension Front-to-Back: 14 1/2”
Dimension Side-to-Side: 7 1/4”
Material: stainless steel
Weight: 1.3

Click for photos

SET OF THREE/3 PACK Stainless steel Flame Tamer for Jenn-Air model JA480. Sold individually, number required varies. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0016-X3
Dimension Front-to-Back: 14 1/2”
Dimension Side-to-Side: 7 1/4”
Material: stainless steel
Weight: 3.6

==> All Jenn-Air Heat Plates.
