Kitchen Aid 720-0826 Grill Parts

Stainless steel burner for Kitchen Aid model 720-0826. Fits premium and designer stainless grills by Charbroil. Includes:

• Made of high quality 304 stainless steel
• Spider exclusion screen
• Ignition electrode mounting holes on both sides of burner
• Back mounting hole is round, inspect your old burner

Part Number: CBP3
Dimensions: 16 15/16
Material: stainless steel
Weight: 1.0

Porcelain steel cooking grids for Kitchen Aid model 720-0826. Porcelain enameled, glossy finish. Sold as a set of three (3). If you prefer a heavier cast iron porcelain enameled glossy finish cooking grid, select four (4) panels of # 65131.

Part Number: 54453
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 31 1/2”
Material: porcelain steel wire
Weight: 15.10

Stainless steel cooking grids for Kitchen Aid model 720-0826. Sold as a set of three (3).

Part Number: 5S793
Dimension Front-to-Back: 18 13/16”
Dimension Side-to-Side: 31 1/2”
Material: stainless steel wire
Weight: 17.1

Cast iron cooking grid for Kitchen Aid model 720-0826. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-68P-CI
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10 1/2”
Material: cast iron
Weight: 7.2

Cast iron cooking grids for Kitchen Aid model 720-0826. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 18 7/8” x 10 1/2”
• Overall dimensions: 18 7/8” x 31 1/2”

Part Number: CG-68P-CI-X3
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 31 1/2”
Material: cast iron
Weight: 21.6

Cast iron cooking grid for Kitchen Aid model 720-0826. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

SET OF FOUR/4 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0826. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X4
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.08

SET OF FIVE/5 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0826. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X5
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.85

Porcelain steel Flame Tamer for Kitchen Aid model 720-0826. Sold individually.

Part Number: 90731
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: porcelain steel
Weight: 1.0

Stainless steel Flame Tamer for Kitchen Aid model 720-0826.

Part Number: NGHP2
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 1.0

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has eight (8) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03388
Dimensions: 3 1/2” x 2”
Weight: 0.5

Ground wire required when replacing spark generator for a valve-triggered electrode with a remote switch-triggered spark generator. 03621 plugs into one switch inlet; ring connects to generator neck; switch wire plugs into the other generator switch inlet

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03621
Dimensions: 1 1/8” x 1 1/8”
Weight: 0.1

20” Ignitor adapter wire with female spade connector and male round connector. Used primarily on Ducane models 7100 and 7200 to extend the wire from the 03758 collector box and electrode to the electronic spark generator (igniter).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03750
Dimensions: 1/16
Weight: 0.05

Electrode with 24.5” wire that has a female spade/flat end. To lengthen the wire use adapter # 03198 and extension wire # 03750.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04432
Dimensions: 4”
Material: ceramic
Weight: 0.1

Universal extention wire, male spade end & female round end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

Burner-mounted ceramic electrode, wire, and mounting bracket.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-19B
Weight: 0.1

Round heat indicator. Single probe. Requires 13/16” mounting hole.

Part Number: 00745
Dimensions: 3 1/8” x 3 1/8”
Weight: 0.3

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
