Outdoor Gourmet B09LB1-32-4 Grill Parts

Stainless steel tube burners for Outdoor Gourmet model B09LB1-32-4. SET OF FOUR (4).

Includes

• SS tube burners
• Electrode mounting brackets
• Spider exclusion screens
• Adjustable air shutters.

Part Number: 10221-X4
Dimensions: 13 1/4” x 1”
Material: stainless steel
Weight: 3.2

Stainless steel burner for Outdoor Gourmet model B09LB1-32-4.

Part Number: OGTB1
Dimensions: 13 1/4
Material: stainless steel
Weight: 1.0

Cast iron cooking grids for Outdoor Gourmet model B09LB1-32-4. Porcelain treated, flat matte finish. Sold as a set of three (3).

Part Number: 64033
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 30 13/16”
Material: matte cast iron
Weight: 16.10

Heat Plate/ Flame Tamer not known for Outdoor Gourmet model B09LB1-32-4. Our parts information for this grill model is incomplete, and we really don't know with certainty which heat plate fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the heat plates we carry for your brand grill. If we don't have the exact fit for your grill, we may have a suitable replacement part. Measure your existing part so you'll know exactly what size is needed.

If you have this grill model and know the number and dimensions of your original heat plates, click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: HP-DUMMY
Weight: 1.0

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

Ignition connection wires used to connect battery powered spark generators to electrodes. SET OF FOUR (4) 47” wires.

• Each wire has female spade connectors on one end and square plastic connectors on the other
• Square plastice connector attaches to spark generator
• Female spade connector ataches to electrode

NOTE: For more information on grill ignition systems, including how to connect electrodes to spark generators/ignitors, see article Ignition 101 in our help center.

Part Number: 03610-X4
Weight: 0.2

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Burner mounted electrodes with male spade connectors. SET OF FOUR (4). Includes small mounting bolts and nuts.

• Wire not included. Commonly used with wire part# 03610.
• Female spade connector on wire connects to male spade connector of electrode.
• If used with existing wire, confirm connecting end of wire is a female spade connector
• Usually, one electrode required per burner

NOTE: Electrodes provide the spark that ignites the gas when the ignitor button is depressed, or the knob is turned. They're the spark plug of the grill. ==> For more information on grill ignition systems, including how to connect electrodes to spark generators/ignitors, see article Ignition 101 in our help center.

Part Number: 04022-X4
Material: ceramic
Weight: 0.4

Electrode to Fit Many Import Grills Including some Kenmore, BBQ Pro, Sam's Club, K-Mart, Etc….

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-31B
Weight: .05

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59
