Bakers & Chefs 9905TB Grill Parts

Cast iron burner for Bakers & Chefs model 9905TB.

Part Number: CISC (Replaces Bakers & Chefs P1925A)
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 5.0

Cast stainless steel burner for Bakers & Chefs model 9905TB. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design..

Part Number: 29251-CSS-X3
Dimensions: 16” x 4 5/8”
Material: cast stainless steel
Weight: 10.05

Cast stainless steel burner for Bakers & Chefs model 9905TB. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design..

Part Number: 29251-CSS
Dimensions: 16” x 4 5/8”
Material: cast stainless steel
Weight: 3.35

Cast iron burners for Bakers & Chefs model 9905TB. SET OF THREE(3).

Part Number: 29251-X3
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 19.2

Cast iron burner for Bakers & Chefs model 9905TB.

Part Number: CISC-X3
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 15.0

Stainless steel burner bracket. Sometimes called a cross over channel. Made in USA.

Part Number: CLA2219 (Replaces Bakers & Chefs P2219A)
Dimensions: 31 1/2
Material: 304 stainless steel
Weight: 2.3

Premium quality stainless steel cooking grid for Bakers & Chefs model 9905TB. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it.

• 304 commercial grade stainless steel
• 1/4” diameter solid stainless rods
• Dimensions: 18 7/8” x 10”
• Made in USA.
• Sold individually.

Part Number: CLS9151
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10”
Material: solid stainless steel
Weight: 4.0

Replacement steel Flame Tamer for Bakers & Chefs model 9905TB. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA1721 (Replaces Bakers & Chefs P1721B)
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 9 3/4”
Material: carbon steel
Weight: 3.5

SET OF THREE/3 PACK Stainless steel Flame Tamer for Bakers & Chefs model 9905TB. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA2721-X3
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 9 3/4”
Material: stainless steel
Weight: 7.2

Stainless steel Flame Tamer for Bakers & Chefs model 9905TB. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA2721
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 9 3/4”
Material: stainless steel
Weight: 2.4

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Black control knob (Some originals may have been chrome).

• Off position D-Value: 12 o'clock
• Knob diameter: 2 3/16”
• Socket diameter: 6mm
• Knob shaft: None

Part Number: 03430
Dimensions: 2 3/16” x 2 3/16”
Material: plastic
Weight: 0.2

Clamp-on brass valve with 45° gas outlet.

• D-Value is 6 o'clock
• Stem diameter: 8mm (about 5/16”)
• Orifice included
• Orifice pre-drilled to #59. For LP, this is approximately 11,654 BTU per burner.

Part Number: 3742C (Replaces Bakers & Chefs P3229T)
Dimensions: 4 3/8” x 1 5/8”
Material: brass
Weight: 0.5

Neoprene valve gasket for clamp-on gas control valves. 19mm.

Part Number: 00019
Dimensions: 0 1/2” x 0 1/4”
Material: neoprene
Weight: 0.01

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

20” Professional Extra Long Tong.
20” Stainless steel tong with red soft grip rubber inserts. Grip your food on the grill with ease. Manual lock saves on storage space.


Part Number: 40269
Material: stainless steel
Weight: 0.14

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0
