BBQTEK GSC2418JBN Grill Parts

Stainless steel tube burner for BBQTEK model GSC2418JBN.

Includes
• SS tube burner
• Electrode mounting bracket (not all models use bracket)
• Spider exclusion screen
• Adjustable air shutter.

NOTE: Some earlier versions of this burner, which are no longer available, were a bit larger in diameter. Some models may not need the electrode tab.


Part Number: 12411
Dimensions: 16 1/2” x 1”
Material: stainless steel
Weight: 0.6

Stainless steel tube burner for BBQTEK model GSC2418JBN. Does not have an electrode bracket attached. If your model needs the electrode bracket, see part number 12411.


Part Number: BBQT1
Dimensions: 16 1/2
Material: stainless steel
Weight: 0.5

Stainless steel burner support bracket. Made in USA.

Part Number: CLA-MS0172
Dimensions: 21 1/4”
Material: stainless steel
Weight: 0.95

Cast Iron Cooking Grid - Brickman, BBQ Grill for BBQTEK model GSC2418JBN.

Part Number: CG-101PCI
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 11 1/2”
Material: cast iron
Weight: 5.80

Cast iron cooking grids for BBQTEK model GSC2418JBN. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 17 3/4” x 11 1/2”
• Overall dimensions: 17 3/4” x 23”

Part Number: CG-101PCI-X2
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 23”
Material: cast iron
Weight: 11.6

Cast iron cooking grids for BBQTEK model GSC2418JBN. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 17 3/4” x 11 1/2”
• Overall dimensions: 17 3/4” x 34 1/2”

Part Number: CG-101PCI-X3
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 34 1/2”
Material: cast iron
Weight: 17.4

Stainless steel heat plate for BBQTEK model GSC2418JBN.


Part Number: BBQHP1
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 1/2”
Material: stainless steel
Weight: 0.7

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

Universal 2 5/16” knob.

• Selectable D-Value
• Selectable socket diameter - 6mm or 8mm.
• Selectable shaft length - flush, 1/4”, or 1 5/8”. Shafts can also be trimmed to desired length.
• Includes 6 shaft inserts and set screw.
• Fits any grill with inside bezel diameter greater than 2 5/16” (the knob diameter).

Part Number: 02342
Dimensions: 2 5/16” x 2 5/16”
Material: plastic
Weight: 0.20

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in many other different grills.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4” 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

WARNING: Before ordering this universal rack, please verify your grill has enough space to accommodate it. If you need to return, you will be responsible for return shipping, and the original out bound shipping fee will be deducted from the refund. What's required?

• Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
• Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside along with food placed on top of the rack.

  Part Number: CLA-WS0040
  Dimensions: 6 1/4” x 22 7/8”
  Material: stainless steel
  Weight: 4.8

Round heat indicator.

• Single probe
• 3” diameter
• Requires 3/8” mounting hole

Part Number: 00016
Dimensions: 3” x 3”
Weight: 0.2

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
