Brinkmann Hampton 810-8445-F Grill Parts

Brinkmann Hampton 4 Burner Heavy-Duty Gas Grill

Highest quality replacement parts for your Brinkmann Hampton 810-8445-F - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-8445-F owners manual and diagrams

Click the small images on the right to view Brinkmann 810-8445-F exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-8445-F-3189916644D839-PartsExpS1.gif

Replacement grill parts for Brinkmann Hampton (810-8445-F)

All of the parts we have for Brinkmann 810-8445-F are shown on this page. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Brinkmann grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Brinkmann 810-8445-F BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-8445-F Burners

Click for photos

Stainless steel burner for Brinkmann model 810-8445-F.

Part Number: UFT1
Dimensions: 15 5/8
Material: stainless steel
Weight: 0.4

Click for photos

Stainless steel burner for OEM # 154-9520-0 for Brinkmann model 810-8445-F.

Part Number: BMTB3 (Replaces Brinkmann 154-8445-0)
Dimensions: 15 5/16
Material: stainless steel
Weight: .70

==> All Brinkmann Burners.

810-8445-F Burner Brackets and Carryovers

Click for photos

Stainless steel cross over tube. Channels gas between burners.

Part Number: BMCO6 (Replaces Brinkmann 600-8445-3)
Dimensions: 2 5/16” x 10 1/4”
Material: stainless steel
Weight: 0.15

==> All Brinkmann Burner Brackets and Carryovers.

810-8445-F Cooking Grids

Click for photos

Cast iron cooking grids for Brinkmann model 810-8445-F. SET OF FOUR (4).

Porcelain treated, matte finish
4 panels, each 17 5/8” x 8 3/4”
Total width: 35”

Part Number: CG-73P-CI-X4
Dimension Front-to-Back: 17 5/8”
Dimension Side-to-Side: 35”
Material: cast iron
Weight: 22.20

Click for photos

Cast iron cooking grids (set of 4) for Brinkmann model 810-8445-F. Porcelain treated, flat matte finish.

Part Number: 64104
Dimension Front-to-Back: 17 5/8”
Dimension Side-to-Side: 35 1/2”
Material: cast iron
Weight: 14.1

==> All Brinkmann Cooking Grids.

810-8445-F Heat Plates

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates for Brinkmann model 810-8445-F. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0135-X4
Dimension Front-to-Back: 15 5/16”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 2.64

Click for photos

Stainless steel Heat Distribution Plate / Flame Tamer for Brinkmann model 810-8445-F.

Part Number: CHMBHP3
Dimension Front-to-Back: 15 3/8”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: .66

==> All Brinkmann Heat Plates.

810-8445-F Igniter Components

Click for photos

Collector box with ceramic electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-22B (Replaces Brinkmann 600-8444-B)
Weight: 0.3

==> All Brinkmann Igniter Components.

810-8445-F Heat indicators and Meat Thermometers

Click for photos

Oval lid heat indicator. Mounts to grill with single 1.25” long threaded temperature probe in center.

Part Number: 072-6800-0 (Replaces Brinkmann 072-7231-0)
Dimensions: 2 15/16” x 1 7/8”
Material: stainless steel
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-8445-F Accessories

Stainless steel straight handle grill brush with replaceable head. Brass bristles and scarper. See part# WB-8RH for replacement grill brush heads. 18 1/2” long.

Part Number: WB-8
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.8

==> All 810-8445-F Accessories.
