Kitchen Aid 720-0893D Grill Parts

Stainless steel burner for Kitchen Aid model 720-0893D. Fits premium and designer stainless grills by Charbroil. Includes:

• Made of high quality 304 stainless steel
• Spider exclusion screen
• Ignition electrode mounting holes on both sides of burner
• Back mounting hole is round, inspect your old burner

Part Number: CBP3
Dimensions: 16 15/16
Material: stainless steel
Weight: 1.0

Stainless steel cooking grid for Kitchen Aid model 720-0893D. Sold as a set of three (3).

Part Number: 5S763
Dimension Front-to-Back: 18 13/16”
Dimension Side-to-Side: 33 3/8”
Material: stainless steel clad wire
Weight: 17.8

SET OF FOUR/4 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0893D. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X4
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.08

SET OF FIVE/5 PACK Stainless steel heat plate/Flame Tamer for Kitchen Aid model 720-0893D. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0158-X5
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 3.85

Porcelain steel Flame Tamer for Kitchen Aid model 720-0893D. Sold individually.

Part Number: 90731
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: porcelain steel
Weight: 1.0

Stainless steel Flame Tamer for Kitchen Aid model 720-0893D.

Part Number: NGHP2
Dimension Front-to-Back: 16 1/8”
Dimension Side-to-Side: 3 3/8”
Material: stainless steel
Weight: 1.0

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.

• 1.5 volt
• Has seven (7) spark outlets (male spade connector)
• Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03387
Dimensions: 3 3/8” x 2”
Weight: 0.5

Ground wire required when replacing spark generator for a valve-triggered electrode with a remote switch-triggered spark generator. 03621 plugs into one switch inlet; ring connects to generator neck; switch wire plugs into the other generator switch inlet

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03621
Dimensions: 1 1/8” x 1 1/8”
Weight: 0.1

electrode with connection

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04436
Material: ceramic
Weight: 1.0

Burner-mounted ceramic electrode, wire, and mounting bracket.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-19B
Weight: 0.1

Round heat indicator. Single probe. Requires 13/16” mounting hole.

Part Number: 00745
Dimensions: 3 1/8” x 3 1/8”
Weight: 0.3

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
