Uniflame GBC956W1-C Grill Parts

Uniflame GBC956W1-C 4-Burner LP gas grill with side burner

Highest quality replacement parts for your Uniflame GBC956W1-C - Free USA shipping $49 or more* - No Sales Tax*

Uniflame GBC956W1-C owners manual and diagrams

Click the small images on the right to view Uniflame GBC956W1-C exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Uniflame GBC956W1-C-4E650433885839-PartsExpS1.gif

Replacement grill parts for the Uniflame model: GBC956W1-C

All of the parts we have for Uniflame GBC956W1-C are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Uniflame grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Uniflame GBC956W1-C BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Uniflame model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

GBC956W1-C Burners

Click for photos

Stainless steel tube burner for Uniflame model GBC956W1-C. Includes

SS tube burner
Electrode mounting bracket
Spider exclusion screen
Adjustable air shutter.

Part Number: 18311 (Replaces Uniflame 55-09-026)
Dimensions: 16 1/8” x 1”
Material: stainless steel
Weight: 0.5

==> All Uniflame Burners.

GBC956W1-C Cooking Grids

Click for photos

Cast iron cooking grids for Uniflame model GBC956W1-C. Porcelain treated, flat matte finish. Sold as a set of two (2).

Part Number: 61192 (Replaces Uniflame 55-09-258)
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 26 1/2”
Material: matte cast iron
Weight: 12.10

Click for photos

Channel formed U-shaped porcelain steel cooking grids for Uniflame model GBC956W1-C. Channel formed means rolled steel stamped into a U-shape; is not solid round rods. Porcelain enameled, glossy finish. Sold as a set of two (2).

Part Number: 59812
Dimension Front-to-Back: 17 3/16”
Dimension Side-to-Side: 27”
Material: stamped porcelain steel
Weight: 7.2

==> All Uniflame Cooking Grids.

GBC956W1-C Heat Plates

Click for photos

Stainless steel Heat Distribution Plate / Flame Tamer for Uniflame model GBC956W1-C.

Part Number: CHMBHP3 (Replaces Uniflame 55-09-018)
Dimension Front-to-Back: 15 3/8”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: .66

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates for Uniflame model GBC956W1-C. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0135-X4
Dimension Front-to-Back: 15 5/16”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 2.64

Click for photos

Stainless steel Flame Tamer for Uniflame model GBC956W1-C.

Part Number: NGKHP1
Dimension Front-to-Back: 15 1/8”
Dimension Side-to-Side: 4 3/16”
Material: stainless steel
Weight: 1.0

==> All Uniflame Heat Plates.

GBC956W1-C Igniter Components

Click for photos

Battery powered push button igniter.

Has six (6) spade type male connectors.
Uses 1 AA battery (not supplied)
Requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB6-B
Weight: 0.3

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Click for photos

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

==> All Uniflame Igniter Components.

GBC956W1-C Accessories

Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

Click for photos

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Click for photos

Stainless steel chicken roaster. Commonly called Beer Can roasters.

The best way to roast poultry on the grill
For use in barbecues and ovens
Dishwasher safe
Includes rack, rack support, and basting brush

Part Number: 41333
Material: stainless steel
Weight: 0.10

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

==> All GBC956W1-C Accessories.
