Brinkmann 810-7440-F Grill Parts

Charmglow 4 Burner Stainless Steel Gas Grill

Highest quality replacement parts for your Brinkmann 810-7440-F - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-7440-F owners manual and diagrams

Diagrams & owners manual not available for grill model# 810-7440-F. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for the Brinkmann model: 810-7440-F

On this page you'll find all of the parts that fit model Brinkmann 810-7440-F. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Brinkmann grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Brinkmann 810-7440-F BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-7440-F Burners

Click for photos

Adjustable universal front-to-back tube burner with top-ported flame holes for Brinkmann model 810-7440-F. This burner may not work with existing ignition electrodes and back burner cross-overs.

Variable length burner adjusts from 13 1/2” to 17 1/2”.
Includes extra hardware and mounting brackets to accommodate almost all grills.
Comes with complete installation instructions and diagrams.

WARNING: Before ordering this universal burner, please verify that it will work in your grill per the specifications above. If you order this universal burner and it does not work in your grill, please review our Return Policy for ”Ordered Wrong Part.” You will be responsible for all shipping fees.

Part Number: FP-BR1001
Material: stainless steel
Weight: 0.7

Click for photos

stainless steel burner for Brinkmann model 810-7440-F.

Part Number: CTB2
Dimensions: 16 1/4
Material: stainless steel
Weight: 1.0

Click for photos

Premium grade 304 stainless burner for Brinkmann model 810-7440-F.

Part Number: CTB3 (Replaces Brinkmann 154-6430-0)
Dimensions: 15 7/8
Material: stainless steel
Weight: 1.0

==> All Brinkmann Burners.

810-7440-F Burner Brackets and Carryovers

Click for photos

Main burner support bracket. Replaces Brinkmann OEM part# 600-6431-B. Made in USA.

Part Number: CLA-MX0046
Dimensions: 24 5/16
Material: stainless steel
Weight: 0.8

==> All Brinkmann Burner Brackets and Carryovers.

810-7440-F Cooking Grids

Click for photos

Cast iron cooking grid for Brinkmann model 810-7440-F. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-58P-CI (Replaces Brinkmann 115-2300-0)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 12 3/8”
Material: cast iron
Weight: 8.35

==> All Brinkmann Cooking Grids.

810-7440-F Heat Plates

Click for photos

SET OF THREE/3 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-7440-F. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.1

Click for photos

SET OF FOUR/4 PACK Stainless steel Heat Distribution Plates/Flame Tamers for Brinkmann model 810-7440-F. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.e.

Part Number: CLA-TS0156-X4
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 3 15/16”
Material: stainless steel
Weight: 2.8

Click for photos

Stainless steel heat distribution plate for Brinkmann model 810-7440-F.

Part Number: BMHP1 (Replaces Brinkmann 600-7310-T)
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 3 7/8”
Material: stainless steel
Weight: 0.7

==> All Brinkmann Heat Plates.

810-7440-F Igniter Components

Click for photos

Battery powered push button igniter.

Has six (6) spade type male connectors.
Uses 1 AA battery (not supplied)
Requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB6-B
Weight: 0.3

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Click for photos

Collector box with ceramic igniter electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-21B (Replaces Brinkmann 600-7541-B)
Weight: 0.2

==> All Brinkmann Igniter Components.

810-7440-F Heat indicators and Meat Thermometers

Click for photos

Oval lid heat indicator. Three-hole mount with two threaded studs 1 1/2” offset on center. Requires 3/8” center hole for temperature sensor probe.

Part Number: 22551 (Replaces Brinkmann 072-7310-0)
Dimensions: 2 15/16” x 1 7/8”
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-7440-F Accessories

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All 810-7440-F Accessories.
