Member's Mark 720-0691A Grill Parts

Member's Mark® 30" LP gas grill. Sam's item# 146622

Highest quality replacement parts for your Member's Mark 720-0691A - Free USA shipping $49 or more* - No Sales Tax*

Member's Mark 720-0691A owners manual and diagrams

Click the small images on the right to view Member's Mark 720-0691A exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Members Mark 720-0691A-324999308730-PartsExpS1.gif

Members Mark 720-0691A-324999308730-PartsLstS1.gif

Members Mark 720-0691A-324999308730-PartsLstS2.gif

Replacement grill parts for Member's Mark model: 720-0691A

On this page you'll find all of the parts that fit model Member's Mark 720-0691A. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Member's Mark grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Member's Mark 720-0691A BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Member's Mark model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

720-0691A Burners

Click for photos

Stainless steel burner for Member's Mark model 720-0691A.

Part Number: CBP6 (Replaces Member's Mark 10000012A0)
Dimensions: 14 3/8” x 1”
Material: stainless steel
Weight: 1.0

==> All Member's Mark Burners.

720-0691A Cooking Grids

Click for photos

Stainless steel 3-piece cooking grid set for Member's Mark model 720-0691A.

Made in USA
SET OR THREE (3)
Solid 1/4” stainless rods

Set Includes:

(1) Grid measuring 17 1/4” x 10-1/4”.
(2) Grids measuring 17 1/4” X 9-3/4”.

Part Number: CG-110SSET (Replaces Member's Mark 13000070A0)
Dimension Front-to-Back: 17 5/16”
Dimension Side-to-Side: 29 3/4”
Material: stainless steel
Weight: 10.7

Click for photos

Cast iron cooking grids for Member's Mark model 720-0691A. Porcelain treated, flat matte finish. Sold as a set of two (2).

Part Number: 64252
Dimension Front-to-Back: 17 1/4”
Dimension Side-to-Side: 28 1/8”
Material: matte cast iron
Weight: 13.12

==> All Member's Mark Cooking Grids.

720-0691A Heat Plates

Click for photos

Stainless steel heat plate/ Flame Tamer for Member's Mark model 720-0691A.

Part Number: NGSAMHP1 (Replaces Member's Mark 04005431A0)
Dimension Front-to-Back: 15 1/4”
Dimension Side-to-Side: 4 7/8”
Material: stainless steel
Weight: 0.6

Click for photos

SET OF FOUR/4 PACK Stainless steel Flame Tamer for Member's Mark model 720-0691A. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0216-X4
Dimension Front-to-Back: 15 1/4”
Dimension Side-to-Side: 4 7/8”
Material: stainless steel
Weight: 3.2

==> All Member's Mark Heat Plates.

720-0691A Igniter Components

Click for photos

Battery powered push button igniter.

Has six (6) spade type male connectors.
Uses 1 AA battery (not supplied)
Requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB6-B
Weight: 0.3

Click for photos

Burner-mounted ceramic electrode, wire, and mounting bracket.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-19B
Weight: 0.1

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

==> All Member's Mark Igniter Components.

720-0691A Accessories

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All 720-0691A Accessories.
