Member's Mark M5205ALP Grill Parts

Member's Mark logo



Member's Mark M5205ALP



Highest quality replacement parts for your Member's Mark M5205ALP - Free USA shipping $49 or more* - No Sales Tax*



Member's Mark M5205ALP owners manual and diagrams
Click the small images on the right to view Member's Mark M5205ALP exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Members Mark M5205ALP-4D449477731-PartsExpS1.gif  Members Mark M5205ALP-4D449477731-PartsLstS1.jpg  Members Mark M5205ALP-4D449477731-PartsLstS2.gif  Members Mark M5205ALP-4D449477731-PartsLstS3.gif

Replacement BBQ grill parts for Member's Mark model: M5205ALP
All of the parts we have for Member's Mark M5205ALP are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Member's Mark grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Member's Mark M5205ALP BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Member's Mark model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



M5205ALP Burners

P02008004A-X3 / P02008004A-R-X3
Click for photos

P02008004A-R-X3 Main Burners for Member's Mark model M5205ALP. SET OF THREE (3). Stainless steel center-fed U burners.

Fits Sam's Club Member's Mark LP models:

  • M3905ALP
  • M5205ALP

Replaces original Member's Mark (Grand Hall) part # P02008004A.
May fit other models



Part Number: P02008004A-R-X3 (Replaces Member's Mark P02008004A-X3)
Dimensions: 16 1/8” x 5 1/8”
Material: stainless steel
Weight: 6.0

$246.39

Qty


P02008004A / P02008004A-R
Click for photos

P02008004A-R Main Burner for Member's Mark model M5205ALP. Stainless steel center-fed U burner.

Fits Sam's Club Member's Mark LP models:

  • M3905ALP
  • M5205ALP

May fit other models.

Replaces original Member's Mark (Grand Hall) part # P02008004A.

Available in an economical 3-burnet set.

Part Number: P02008004A-R (Replaces Member's Mark P02008004A)
Dimensions: 16 1/8” x 5 1/8”
Material: stainless steel
Weight: 2.0

$87.73

Qty


==> All Member's Mark Burners.






M5205ALP Cooking Grids

P01604002B / CLA-GS0005
Click for photos

Premium quality heavy duty stainless steel cooking grid for Member's Mark model M5205ALP. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 6 pounds of solid stainless each.

  • 304 commercial grade stainless steel
  • Large diameter 5/16” solid stainless rods
  • Dimensions: 19 1/4” x 10 1/4”
  • Made in USA.
  • Sold individually.

See part CLA-GS0005-X3 for a more economical 3-pack.



Part Number: CLA-GS0005 (Replaces Member's Mark P01604002B)
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 1/4”
Material: stainless steel
Weight: 6.3

$101.27

Qty


CG-69P-CI
Click for photos
Cast iron cooking grid for Member's Mark model M5205ALP.
  • Sold inividually
  • Porcelain treated, matte finish
  • Number required varies by grill model
  • Each panel measures 19 1/4” x 10 3/8”


Part Number: CG-69P-CI
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 3/8”
Material: cast iron
Weight: 7.10

$60.53

Qty


CLS9151
Click for photos

Premium quality stainless steel cooking grid for Member's Mark model M5205ALP. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it.

  • 304 commercial grade stainless steel
  • 1/4” diameter solid stainless rods
  • Dimensions: 18 7/8” x 10”
  • Made in USA.
  • Sold individually.


Part Number: CLS9151
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10”
Material: solid stainless steel
Weight: 4.0

$38.34

Qty


506S3
Click for photos
Stainless steel cooking grid set for Member's Mark model M5205ALP.
  • 5/16” diameter stainless rods
  • 304 stainless steel


Part Number: 506S3
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 32 3/8”
Material: stainless steel
Weight: 15.1

$205.72

Qty


CG-69P-CI-X3
Click for photos
Cast iron cooking grids for Member's Mark model M5205ALP. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 19 1/4” x 10 3/8”
  • Overall dimensions: 19 1/4” x 31 1/8”


Part Number: CG-69P-CI-X3
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 31 1/8”
Material: cast iron
Weight: 21.3

$159.93

Qty


==> All Member's Mark Cooking Grids.






M5205ALP Heat Plates

P01717002E / P01717002E-R
Click for photos

Savor Plate Rack for Member's Mark model M5205ALP. Heavy duty, 304 premium grade stainless steel with 5/16” rods. Each rack holds three (3) P01804006A-R ceramic flame tamers (sold separately).

NOTE: This is an aftermarket part made to replace original part number P01717002E, which is no longer available.

Fits models:

  • M5205ALP
  • M5205ANG
  • and others



Part Number: P01717002E-R (Replaces Member's Mark P01717002E)
Dimension Front-to-Back: 17 3/8”
Dimension Side-to-Side: 9”
Material: stainless steel
Weight: 1.0

$31.14

Qty


P01804006A / P01804006A-R
Click for photos
Ceramic Savor Plate for Member's Mark model M5205ALP. Measures 7 1/16” x 4 3/4”. Box of 4.

Note: This part is used in racks P01717003E, and P01717002E.

Fits models:
  • M3905ALP
  • M3905ANG
  • M5205ALP
  • M5205ANG
  • And others



Part Number: P01804006A-R (Replaces Member's Mark P01804006A)
Dimension Front-to-Back: 7 1/16”
Dimension Side-to-Side: 4 3/4”
Material: ceramic
Weight: 4.0

$45.00
SALE  $34.99
Qty


==> All Member's Mark Heat Plates.






M5205ALP Igniter Components

P02502134C / IGEIB4-B
Click for photos
Battery powered push button igniter.
  • Has four (4) spade type male connectors.
  • Uses 1 AAA battery (not supplied)
  • Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB4-B (Replaces Member's Mark P02502134C)
Weight: 0.3

$34.08

Qty


TS-IG4010
Click for photos
Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: TS-IG4010
Weight: 0.2

$18.48

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


==> All Member's Mark Igniter Components.






M5205ALP Accessories

BRGG
Click for photos
Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

$20.11

Qty


WB-8RH
Click for photos
Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

$9.45

Qty


==> All M5205ALP Accessories.
