Coleman 7700 9992-646 Grill Parts

Coleman 7700 LP gas series

Highest quality replacement parts for your Coleman 7700 9992-646 - Free USA shipping $49 or more* - No Sales Tax*

Coleman 9992-646 owners manual and diagrams

Click the small images on the right to view Coleman 9992-646 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Coleman 9992-646-30004436331-PartsExpS1.jpg

Coleman 9992-646-30004436331-PartsLstS1.jpg

Replacement BBQ grill parts for Coleman 7700 9992-646

On this page you'll find all of the parts that fit model Coleman 9992-646. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Coleman grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Coleman 9992-646 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Coleman model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

9992-646 Burners

Click for photos

Cast stainless steel burner for Coleman model 9992-646. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design.

NOTE: This burner is equiped with an air intake adjustable control shutter (not shown in photos) and with an air intake control screw for regulating the air/gas mixture into the burner. Natural gas applications require more air (more open screw) than lquid propane (LP). If necessary, adjust screw to get a yellow-tipped blue flame.

Part Number: 23301-CSS
Dimensions: 16” x 2 7/16”
Material: cast stainless steel
Weight: 3.2

Click for photos

Cast iron burner for Coleman model 9992-646.

Part Number: CIT
Dimensions: 15 3/4” x 2 7/8”
Material: cast iron
Weight: 4.2

==> All Coleman Burners.

9992-646 Cooking Grids

Click for photos

Cast iron cooking grid for Coleman model 9992-646. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

==> All Coleman Cooking Grids.

9992-646 Heat Plates

Click for photos

Stainless steel Heat Tent for Coleman model 9992-646.

Part Number: COHP1
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 6 1/4”
Material: stainless steel
Weight: 1.45

==> All Coleman Heat Plates.

9992-646 Warming Racks

Click for photos

Universal warming rack. For use on grills with at least 22” inside dimension.

Part Number: AP-6A
Dimensions: 6” x 21 1/2”
Material: Chrome steel
Weight: 1.3

==> All Coleman Warming Racks.

9992-646 Accessories

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Click for photos

Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2

==> All 9992-646 Accessories.
