Coleman Even Heat G52229 Grill Parts

Cast iron cooking grids for Coleman model G52229. Porcelain treated, flat matte finish. Sold as a set of three (3).

Part Number: 65253
Dimension Front-to-Back: 18 3/8”
Dimension Side-to-Side: 26 7/16”
Material: matte cast iron
Weight: 16.5

Porcelain steel Heat Distribution Plate for Coleman model G52229. Sold individually.

Part Number: 93331
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 5 13/16”
Material: porcelain steel
Weight: 1.4

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

round trigger switch for AA and AAA spark generators; use original wires

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03153
Dimensions: 17 3/4” x 1”
Weight: 0.1

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger switch.

Note: Some original ignitors (spark generators) that 03352 replaces had an integrated/built-in ground wire which is not present on this part (03352). If the ignitor you are replacing has an integrated/built-in ground wire, you will also need our ground wire part 03621. Inspect your system.

• 1.5 volt
• Has five (5) spark outlets (male spade connector)
• Has two (2) male spade connectors for the button/trigger switch part 03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/trigger switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03352
Dimensions: 3 3/8” x 2”
Weight: 0.7

electrode

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 05223
Material: ceramic
Weight: 0.1

Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.

• Requires minimum 3/8” mounting hole
• Single 1 3/8” probe
• Threaded portion of probe stops at 1/2” from base
• See photo for details

Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Replacement brass bristle brush head for WB-8 brush. Screws included.

Part Number: WB-8RH
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.2
