Coleman Even Heat G53101 Grill Parts

Coleman logo



Coleman G53101

Coleman EVEN HEAT™ Duel Fuel Charcoal/Propane Barbecue



Highest quality replacement parts for your Coleman Even Heat G53101 - Free USA shipping $49 or more* - No Sales Tax*



Coleman G53101 owners manual and diagrams
Click the small images on the right to view Coleman G53101 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Coleman G53101-4E4589833-PartsExpS1.jpg  Coleman G53101-4E4589833-PartsLstS1.gif

Replacement grill parts for Coleman Even Heat (G53101)
All of the parts we have for Coleman G53101 are shown on this page. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a Flame Tamer/Heat Plate and there are none here, click the Heat Plate button to see all of the Heat Plates we have for Coleman grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Coleman G53101 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Coleman model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



G53101 Cooking Grids

65253
Click for photos
Cast iron cooking grids for Coleman model G53101. Porcelain treated, flat matte finish. Sold as a set of three (3).

Part Number: 65253
Dimension Front-to-Back: 18 3/8”
Dimension Side-to-Side: 26 7/16”
Material: matte cast iron
Weight: 16.5

$124.81

Qty


==> All Coleman Cooking Grids.






G53101 Heat Plates

93331
Click for photos
Porcelain steel Heat Distribution Plate for Coleman model G53101. Sold individually.

Part Number: 93331
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 5 13/16”
Material: porcelain steel
Weight: 1.4

$19.44

Qty


==> All Coleman Heat Plates.






G53101 Igniter Components

03152
Click for photos
Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:
  • Push-button ignition module switch with two male spade connectors on back
  • Two 20” wires with female spade connectors
  • One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

$20.78

Qty


03153
Click for photos
round trigger switch for AA and AAA spark generators; use original wires

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03153
Dimensions: 17 3/4” x 1”
Weight: 0.1

$10.87

Qty


03332
Click for photos
Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.
  • 1.5 volt
  • Has three (3) spark outlets (male spade connector)
  • Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
  • Uses a single AA battery (not included)
  • Requires 7/8” mounting hole
NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03332
Dimensions: 2 5/8” x 2 5/8”
Weight: 0.3

$35.57

Qty


05223
Click for photos
electrode

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 05223
Material: ceramic
Weight: 0.1

$9.42

Qty


==> All Coleman Igniter Components.






G53101 Heat indicators and Meat Thermometers

00012
Click for photos
Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.
  • Requires minimum 3/8” mounting hole
  • Single 1 3/8” probe
  • Threaded portion of probe stops at 1/2” from base
  • See photo for details


Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

$15.90

Qty


==> All Coleman Heat indicators and Meat Thermometers.






G53101 Accessories

FS-1
Click for photos
Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

$17.27

Qty


BRGG
Click for photos
Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

$20.11

Qty


WB-3
18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

$12.50

Qty


==> All G53101 Accessories.
