Member's Mark M3207ALP Grill Parts

Member's Mark logo



Member's Mark M3207ALP

Member's Mark Stainless 3-burner LP gas grill with infrared searing burner, rear rotis burner, and side burner



Highest quality replacement parts for your Member's Mark M3207ALP - Free USA shipping $49 or more* - No Sales Tax*



Member's Mark M3207ALP owners manual and diagrams
Click the small images on the right to view Member's Mark M3207ALP exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Members Mark M3207ALP-4D549277731-PartsExpS1.gif  Members Mark M3207ALP-4D549277731-PartsLstS1.gif

Replacement grill parts to fit Member's Mark model: M3207ALP
On this page you'll find all of the parts that fit model Member's Mark M3207ALP. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Member's Mark grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Member's Mark M3207ALP BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Member's Mark model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



M3207ALP Burners

P02008024A / SCTB5
Click for photos
Sam's Club burner W/ Lip like OEM for Member's Mark model M3207ALP.

Part Number: SCTB5 (Replaces Member's Mark P02008024A)
Dimensions: 14 3/4
Material: stainless steel
Weight: 0.7

$34.96

Qty


==> All Member's Mark Burners.






M3207ALP Cooking Grids

P01604015A / 506S3
Click for photos
Stainless steel cooking grid set for Member's Mark model M3207ALP.
  • 5/16” diameter stainless rods
  • 304 stainless steel


Part Number: 506S3 (Replaces Member's Mark P01604015A)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 32 3/8”
Material: stainless steel
Weight: 15.1

$205.72

Qty


==> All Member's Mark Cooking Grids.






M3207ALP Heat Plates

P01708007B / CLA-TS0314
Click for photos
Stainless steel Savor Plate, also known as Flamer Tamer and Heat Plate for Member's Mark model M3207ALP. Sold individually. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0314 (Replaces Member's Mark P01708007B)
Dimension Front-to-Back: 16 3/8”
Dimension Side-to-Side: 4 1/16”
Material: stainless steel
Weight: .75

$27.28

Qty


P01708007B / SCHP4
Click for photos
Stainless steel heat plate; also referred to as a flame tamer and savor plate for Member's Mark model M3207ALP.

Part Number: SCHP4 (Replaces Member's Mark P01708007B)
Dimension Front-to-Back: 16 3/8”
Dimension Side-to-Side: 3 13/16”
Material: stainless steel
Weight: 1.0

$27.28

Qty


==> All Member's Mark Heat Plates.






M3207ALP Igniter Components

P02609002B / IG-17B
Click for photos
Stainless steel collector box and ceramic electrode with round connector. Includes mounting nuts and washer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-17B (Replaces Member's Mark P02609002B)
Weight: 0.11

$10.81

Qty


P02502218C / 03352
Click for photos
Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger switch.

Note: Some original ignitors (spark generators) that 03352 replaces had an integrated/built-in ground wire which is not present on this part (03352). If the ignitor you are replacing has an integrated/built-in ground wire, you will also need our ground wire part 03621. Inspect your system.
  • 1.5 volt
  • Has five (5) spark outlets (male spade connector)
  • Has two (2) male spade connectors for the button/trigger switch part 03152 (sold separately)
  • Uses a single AA battery (not included)
  • Requires 7/8” mounting hole
  • Overall dimensions: 2” x 3 3/8” x 2 5/8”
NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/trigger switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03352 (Replaces Member's Mark P02502218C)
Dimensions: 3 3/8” x 2”
Weight: 0.7

$39.86

Qty


03152
Click for photos
Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:
  • Push-button ignition module switch with two male spade connectors on back
  • Two 20” wires with female spade connectors
  • One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

$20.78

Qty


03621
Click for photos
Ground wire required when replacing spark generator for a valve-triggered electrode with a remote switch-triggered spark generator. 03621 plugs into one switch inlet; ring connects to generator neck; switch wire plugs into the other generator switch inlet

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03621
Dimensions: 1 1/8” x 1 1/8”
Weight: 0.1

$6.55

Qty


10342-T14
Click for photos
21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

$4.32

Qty


IG-7B
Click for photos
20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-7B
Weight: 0.02

$4.75

Qty


IG-20B
Click for photos
Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-20B
Weight: 0.05

$6.70

Qty


==> All Member's Mark Igniter Components.






M3207ALP Accessories

FS-1
Click for photos
Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

$17.27

Qty


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$8.84

Qty


WB-3
18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

$12.50

Qty


==> All M3207ALP Accessories.
