Member's Mark M3207ANG Grill Parts

Sam's Club burner W/ Lip like OEM for Member's Mark model M3207ANG.

Part Number: SCTB5 (Replaces Member's Mark P02008024A)
Dimensions: 14 3/4
Material: stainless steel
Weight: 0.7

Stainless steel cooking grid set for Member's Mark model M3207ANG.

• 5/16” diameter stainless rods
• 304 stainless steel

Part Number: 506S3 (Replaces Member's Mark P01604015A)
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 32 3/8”
Material: stainless steel
Weight: 15.1

Stainless steel Savor Plate, also known as Flamer Tamer and Heat Plate for Member's Mark model M3207ANG. Sold individually. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0314 (Replaces Member's Mark P01708007B)
Dimension Front-to-Back: 16 3/8”
Dimension Side-to-Side: 4 1/16”
Material: stainless steel
Weight: .75

Stainless steel heat plate; also referred to as a flame tamer and savor plate for Member's Mark model M3207ANG.

Part Number: SCHP4 (Replaces Member's Mark P01708007B)
Dimension Front-to-Back: 16 3/8”
Dimension Side-to-Side: 3 13/16”
Material: stainless steel
Weight: 1.0

Stainless steel collector box and ceramic electrode with round connector. Includes mounting nuts and washer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-17B (Replaces Member's Mark P02609002B)
Weight: 0.11

Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger switch.

Note: Some original ignitors (spark generators) that 03352 replaces had an integrated/built-in ground wire which is not present on this part (03352). If the ignitor you are replacing has an integrated/built-in ground wire, you will also need our ground wire part 03621. Inspect your system.

• 1.5 volt
• Has five (5) spark outlets (male spade connector)
• Has two (2) male spade connectors for the button/trigger switch part 03152 (sold separately)
• Uses a single AA battery (not included)
• Requires 7/8” mounting hole
• Overall dimensions: 2” x 3 3/8” x 2 5/8”

NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/trigger switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03352 (Replaces Member's Mark P02502218C)
Dimensions: 3 3/8” x 2”
Weight: 0.7

Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:

• Push-button ignition module switch with two male spade connectors on back
• Two 20” wires with female spade connectors
• One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

Ground wire required when replacing spark generator for a valve-triggered electrode with a remote switch-triggered spark generator. 03621 plugs into one switch inlet; ring connects to generator neck; switch wire plugs into the other generator switch inlet

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03621
Dimensions: 1 1/8” x 1 1/8”
Weight: 0.1

21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-7B
Weight: 0.02

Burner-mounted ceramic igniter electrode with mounting bracket and hardware.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-20B
Weight: 0.05

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
