Member's Mark PG-4030400LG Grill Parts

Stainless steel burner with electrode-mounting bracket for Member's Mark model PG-4030400LG. The bracket is not used on all grill models. If your model does not use a burner-mounted electrode, just ignore the bracket.

Part Number: 16251
Dimensions: 14 3/4” x 1”
Material: stainless steel
Weight: 0.6

Cooking Grid 304 Grade Stainless Steel for Member's Mark model PG-4030400LG.225” Rods.

Part Number: CG-51SS
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 11 1/4”
Material: stainless steel
Weight: 3.50

Cast Iron cooking grid for Member's Mark model PG-4030400LG.

Part Number: CG-92P-CI
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 11 3/8”
Material: cast iron
Weight: 10

Cast iron cooking grids for Member's Mark model PG-4030400LG. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 16 1/2” x 11 3/8”
• Overall dimensions: 16 1/2” x 22 3/4”

Part Number: CG-92P-CI-X2
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 22/4”
Material: cast iron
Weight: 20

Premium quality stainless steel cooking grids for Member's Mark model PG-4030400LG. SET OF TWO (2). Far superior to the porcelain coated steel grids it replaces.

• Made in USA
• 304 commercial grade stainless steel
• .225 diameter solid stainless rods

• Each panel measures 16 1/2” x 11 1/4”
• Overall dimensions: 16 1/2” x 22 1/2”

.

Part Number: CG-51SS-X2
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 22 1/2”
Material: stainless steel
Weight: 7.0

SET OF FOUR/4 PACK Stainless steel heat plate for Member's Mark model PG-4030400LG. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0193-X4
Dimension Front-to-Back: 14 15/16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 2.6

Stainless steel heat plate/ Flame Tamer for Member's Mark model PG-4030400LG.

Part Number: KENHP3
Dimension Front-to-Back: 14 15/16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.6

Push-button electronic igniter with three (3) spade connectors. Comes with sliver or black cap per availability. Needs (1) AA battery (not included); requires 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG3007
Weight: 0.2

Electrode and wire. Includes mounting bolt and nut. Wire connects to spark generator with flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center). Includes an extra 16” connector wire with flat female spade end and male spade end for some applications (not shown in photo).

Part Number: 00162
Material: ceramic
Weight: 0.1

Universal three-outlet battery powered push button ignitor.

• 1.5 volt
• Has three (3) terminals (male spade connector)
• Uses a single AA battery (not included)
• 03610 and 03620 wires are commonly used with this igniter (not included)
• Requires 7/8” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03333
Dimensions: 2 9/16” x 2”
Weight: 0.5

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in many other different grills.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4” 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

WARNING: Before ordering this universal rack, please verify your grill has enough space to accommodate it. If you need to return, you will be responsible for return shipping, and the original out bound shipping fee will be deducted from the refund. What's required?

• Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
• Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside along with food placed on top of the rack.

  Part Number: CLA-WS0040
  Dimensions: 6 1/4” x 22 7/8”
  Material: stainless steel
  Weight: 4.8

Heat indicator with a single probe and requires a 5/16” mounting hole. Note, the back side DOES NOT have an alignment pin.

Part Number: 00021
Dimensions: 3 5/8” x 1 3/4”
Weight: 0.2

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Universal Grid Lifting Tool

Part Number: BRGG
Weight: 1.0

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.


Part Number: RR-2
Material: chrome steel
Weight: 1.0

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3
